• Membrane switch
• Flexible circuit
• Circuit board

• Silver Ink
• Carbon Ink
• Dielectric
• Silver through hole

CI-1001

Conductive silver ink

High conductivity

<0.015Ω/□.mil

120℃ 20mins

CI-1001B

Conductive silver ink

High conductivity, low cost

<0.015Ω/□.mil

120℃ 20mins

CI-1036

Conductive silver ink

Very high conductivity, good flexibility and stretchable

<0.010Ω/□.mil

110℃ 20mins

CI-1075

Conductive silver ink

Good flexibility and elongation for IMD applications

<0.010Ω/□.mil

120℃ 10mins

CI-1088

Conductive silver ink

Low temperature curing

<0.025Ω/□.mil

50℃ 10mins

CI-800

Conductive silver ink

High conductivity, good flexibility, good adhesion

<0.015Ω/□.mil

120℃ 30mins

CI-801

Conductive silver ink

Very high conductivity, fine line printing

<0.009Ω/□.mil

130℃ 30mins

CI-804

Conductive silver ink

For PC antenna printing

<0.010Ω/□.mil

120℃ 30mins

CI-2001

Conductive carbon ink

Abrasion resistance, for silver contacts

<20Ω/□.mil

110℃ 20mins

CI-2001XL

Conductive carbon ink

Low viscosity for using with CI-2001

Not to be used alone

110℃ 20mins

CI-2018

Conductive carbon ink

Fine line printing for zebra connectors

<12Ω/□.mil

120℃ 30mins

CI-2018H

Conductive carbon ink

High viscosity, low resistance, for PCB

<11Ω/□.mil

120℃ 30mins

CI-2018L

Conductive carbon ink

Low viscosity for using with CI-2018H

<50Ω/□.mil

120℃ 30mins

CI-2002

Conductive carbon ink for heater

For heater application, temperature resistant

<50Ω/□.mil

110℃ 20mins

CI-2022

Conductive carbon ink for heater

High electrical resistance, use with CI-2002

<20kΩ/□.mil

110℃ 20mins

CI-2050

Conductive carbon ink

Pressure sensitive carbon ink

<22Ω/□.mil

110℃ 10mins

CI-2051

Conductive carbon ink

Stretchable carbon ink

<50Ω/□.mil

90℃ 5mins

CI-2062

Conductive carbon ink

Positive temperature coefficient carbon ink

<50Ω/□.mil

90℃ 5mins

CB-F1023

Conductive carbon ink

For ITO connection in LCD

<15Ω/□.mil

80℃ 15mins

DI-7502

UV curing dielectric

General purpose UV dielectric

>800V/mil

750mJ/cm²

DI-7502B

UV curing dielectric

Blue version of DI-7502

>800V/mil

750mJ/cm²

DI-7502C

UV curing dielectric

Clear version of DI-7502

>800V/mil

750mJ/cm²

DI-7502LH

UV curing dielectric

Halogen free, light green version of DI-7502

>800V/mil

750mJ/cm²

DI-702

UV curing dielectric

Low cost dielectric for general purposes

>800V/mil

750mJ/cm²

DI-702C

UV curing dielectric

Clear version of DI-702

>800V/mil

750mJ/cm²

DI-7544

UV curing dielectric

Resistant to high temperature and humidity

>800V/mil

750mJ/cm²

D04-132

UV curing spacer

For space printing, high viscosity

>800V/mil

750mJ/cm²

DI-701

Heat curing dielectric, green

General purpose, heat curing

>800V/mil

130℃ 20mins

DI-701C

Heat curing dielectric, clear

Good adhesion to ITO, good compatibility with various silver inks

>800V/mil

130℃ 20mins

DA-5100

LED surface mount silver epoxy

Very good adhesion

<0.0006 Ω.cm

130℃ 90mins

EC-9519

LED encapsulant

UV curing, low stress, elastic

>800V/mil

750mJ/cm²
